Metal Forming Machines

Press Brakes

CRONOSS SPB 200 TON X 4MT SERVO ABKANT PRES

İlan No

229582

Marka

Cronoss Tech

Yıl / Model

2024 / SPB 200X4MT

Fiyat

Fiyat Sor

Sahibi

Satıcıdan

Durumu

Yeni

İlan Tarihi

15.12.2024

PINAR ÇAR METAL İŞLEME VE TAKIM TEZGAHLARI

Telefon

0212 5496356

Adres

Türkiye / İstanbul / Başakşehir

Yetkili Kişi

Volkan ÖZGÜN

Telefon

0544 3020061

Açıklama Harita Paylaş

Mesaj Gönder Tüm İlanları Favoriye Ekle Mağaza

Standard Specifications
Esa 875 W 3D (3D graphical CNC controller )
2D offline programing system for CNC controller
4 Axes (Y1, Y2, X, R)
(X-R) Axes
Sliding Front Arms with Height Adjustment
Side and Back Safety covers
Electirc Cabinet Cooling Ssystem
Manual European Type (Promecam)
Foot pedal with emergency stop
380 V, 50-60 Hz, 3 Ph
Nylon Coverage

BENDING LENGHT	:	4080	mm
BENDING CAPACITIY	:	200	tons
STROKE	:	300	mm
APPROACHING SPEED	:	75	mm/sec
BENDING SPEED	:	20	mm/sec
RETURNING SPEED	:	75	mm/sec
Dstance Between Tables (Q)	:	590	mm
X AXIS STROKE	:	750	mm
X AXIS MOVING SPEED	:	300	mm/sec
LENGHT	:	5755	mm
WIDTH	:	2460	mm
HEIGHT	:	2800	mm
MAIN MOTOR POWER	:	22	kW
APPROXIMATE WEIGHT	:	14900	kg

Optional Features with Discount
BACKGAUGE			X R Z1 Z2 axis with servo motors
TOOLS			Quick Release Clamping
CONTROL UNIT			DELEM 66T
CONTROL UNIT			DELEM 69T
SAFETY			DSP-AP Safety System
