| | | HDC180 |
Kitleme Gücü | | Clamping force | KN 1800 |
Kitleme Mesafesi | | Clamping stroke | mm 380 |
Itici Kuvveti | | Ejection force | KN 125 |
Itici Uzunlugu | | Ejection stroke | mm 85 |
Kalip Kaling! | | Mold thickness (min-max) | mm 250-600 |
Plaka Boyutlari | | Platen Size (Horizontal × Vertical) mm | 710×710 |
Kolonlar Arasi Mesafe / | | Tie Bar Spacing (Horizontal × Vertical) mm | 460×460 |
Kolon Çapi | | Tie Bar Diameter | mm 0 90 - ---- |
Enjeksiyon Gücü / | | Injection Force (Intensified) | KN 300 |
Enjeksiyon Mesafesi / | | Injection stroke | mm 350 |
Piston Ucu Çapi | | Plunger Tip Diameter | mm 40/50/60 |
Enjeksiyon Boyutu ( Aliminyum ) Injection volume (aluminum) | | | kg 0.8/1.3/1.9 |
Dökum Basinci | / Casting Pressure (Intensified) | | MPa 239/153/106 |
Döküm Alani | Casting area | | cm? 75/117/170 |
Max. Döküm Alani / | | Maximum casting area (40MP) | cm? 450 |
Enjeksiyon Pozisyonu / | | Injection position | mm -140 |
Piston Ucu Cikintisi | Plunger Tip Protrusion | | mm 147 |
Ocak Çapi | Shot Sleeve Flange Diameter | | mm 101.6 |
Piston Atis Alani ile Sabit Plaka Aras! Mesafe | | Shot Sleeve Flange Protrusion From Fixed Platen | mm 12 |
Sistem Basinci | / | System working pressure | MPa 16 |
Motor / Servo Motor Gücü 1 Motor power/servo motor power | | | kW 15/18.5 |
Yag Tanki Kapasitesi | | Hydraulic Oil Filling Volume | | L 400 |
Makine Tonaji | | Lifting reference weight | 6.8 |
Makine Boyutu (Uzun. × Gen. × Yüks.) | | Overall dimension (L × W × H) | mm 5950×1650×2700 |
